Hitachi CP-WU8440 4200 Ansi FULL HD Projeksiyon,1920x1200

Hitachi CP-WU8440 4200 Ansi FULL HD Projeksiyon,1920x1200

• Optical

• LCD Panel

  0.76" (1.9cm) P-Si TFT x3

• Resolution

  WUXGA (1920 x 1200)

• Light Output (Brightness)

  4200 ANSI Lumens (Normal Mode)
  2850 ANSI Lumens (Eco Mode)

• Brightness

  4200 ANSI Lumens (Normal Mode)
  2850 ANSI Lumens (Eco Mode)

• Contrast Ratio

  3000:1 (Presentation Mode)

• Lens (CP-X8160)

  Powered Zoom x 2.0, Powered Focus

• Lamp Wattage

  245W UHP

• Lamp Life

  2500 Hours (Normal Mode)/4000 Hours (Eco Mode)*

• Distance To Width Ratio

  1.5 (Wide), 3.0 (Tele)

• Diagonal Display Size

  30"~600" (76cm~1,524cm)

• Number Of Colours

  8 Bit/colour, 16.7M colours

• Keystone Vertical

  10:-1 shift, Normal at + 14.6°~7.4° projection angle

• Lamp Life Disclaimer

  *The stated lamp life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps should achieve this figure.

• Compatibility

• Computer Compatiblity

  VGA, SVGA, XGA, WXGA, WXGA+, SXGA,SXGA+, UXGA, WUXGA, MAC 16"

• Composite/S-Video

  NTSC/PAL/SECAM/ PAL-M/PAL-N/NTSC4.43

• Component Video/HDMI

  525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)

• Features

• Speakers

  2 x 8W (stereo)

• Basic Functions

  Freeze, Magnifying, Blank, Auto adjustment, Search

• Picture Adjustments

  Equalising digital gamma correction, 2-3 Pull Down for NTSC, progressive scan, noise reduction, Mirror Reverse Image, Up-side Down Image, Equalising colour temperature adjustment, Frame lock, Perfect Fit

• Digital Keystone

  Auto Vertical Keystone correction ±35°, Horizontal Keystone correction ±15°

• Advanced Features (CP-WX8440)

  Audio pass through, Audio ports assign, Auto Eco Mode, Closed caption (NTSC & 480i), Filter timer, Lens memory, My Button, My Memory, My Text, MyScreen, PC-less presentation, Picture modes (normal, cinema, dynamic, blackboard, greenboard, whiteboard, daytime, DICOM simulation), Resolution setting, Source naming (English), Template, Instant Stack, iOS Connectivity, Picture by Picture

• Outward

  Easy lamp replace from side, Easy filter replace from side

• Power On & Off

  Direct power on, Auto power off

• Security Systems

  PIN Security Lock, MyScreen Password Lock, Transition Detector, My Text Password Lock, Key Lock (keypad, remote control), Lens Lock, Security bar

• Network

  AMX Device Discovery, Command control via the network, Configuring and controlling the projector via a web browser, Controlling the projector via scheduling, Crestron RoomView® (not accessible through the wireless adaptor), Displaying text data with audio alarm transferred via network, Failure and warning alerts via email, My Image (still image transfer) Display, Network Bridge, Network Presentation (PC still/moving picture transfer), PJLink™, Projector management via SNMP

• OSD Languages (CP-X3021WN)

  English, French, German, Spanish, Italian, Norwegian, Dutch, Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Swedish, Russian, Finnish, Polish, Turkey, Arabian, Persian, Czech, Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian, Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese

• Connections

• Digital Input

  2 x HDMI (HDCP Compliant)

• Computer Input

  1 x 15-pin Mini D-sub
  1 x BNC

• Monitor Output

  15-pin Mini-D-sub x 1

• Video Input

  1 x S-Video
  1 x RCA Composite Video
  3 x RCA Component Video

• Audio Input

  2 x Stereo Mini Jack
  2 x RCA Jack(L/R)

• Audio Output

  2 x RCA Jack (L/R)

• Control

  1 x 9-pin for RS-232C control

• USB

  2 x USB type A (PC-less presentation or optional wireless adaptor)
  1 x USB type B (USB mouse control or USB display)

• Wired Remote Control

  Input: 1 x Stereo Mini Jack
  Output: 1 x Stereo Mini Jack

• Wired Network

  1 x RJ-45 (10BASE-T/100BASE-TX)

• Wireless Network

  IEEE802.11b/g/n (Optional USB wireless adaptor is required)

• Power

• Power Supply

  AC100-120V/AC220-240V

• Power Consumption/Standby

  355W/<0.35W (AC220-240V)

• Physical

• Dimensions (W X H X D)

  498 x 135 x 396mm (excluding feet and extrusions)

• Weight

  Approximately 8.7Kg

• Noise Level

  35dB (Normal)/29dB (Eco) TBD

• Air Filter

  Hybrid (up to 15,000 hours)

• Miscellaneous

• Miscellaneous

  LED lamps (power, lamp, temperature, security, filter, shade), Serial number label on side

• Certification

• Certification D1

  UL 60950-1/cUL, FCC Part15 subpart B class A, CE Marking EN61000-3-2, EN61000-3-3, EN55022 class A, EN55024 (EMC directive), EN60950-1 (Low voltage directive), WEEE/RoHS/ErP (lot 6 stage 2) compliant, c-tick class A, GOST-R

• Accessories Supplied

• Accessories Supplied (CP-X8150)

  Remote control with batteries, RGB cable, power cord, lens cover, security label, user manual (detail & concise), Application CD, Adaptor cover

• Optional Accessories

• Replacement Lamp

  DT01281

• Filter Set

  MU06642

• USB Wireless Adaptor

  USB-WL-11N

• Solution Products

  TB-1 wireless interactive tablet, IM-1P interactive camera unit, MS-1WL wireless multi-functional switcher, MS-1 multi-functional switcher

• Optional Lenses

  FL-701 - Motorized (focus only) - Fixed lens, Zoom x 1
  SL-702 - Motorized - Short Throw Lens, Zoom x 1.5
  ML-703 - Motorized - Middle throw lens, Zoom x 2
  LL-704 - Motorized - Long throw lens, Zoom x 1.7
  UL-705 - Motorized - Ultra long throw lens, Zoom x 1.7
